Description:
The CQ Spin-On Lube Filter 85320 is designed to help maintain cleaner engine oil by filtering fine contaminants from the lubrication system in bypass filtration applications. Using enhanced cellulose media with a nominal 10-micron rating, this filter helps capture dirt, sludge, and metal particles that can contribute to premature engine wear and reduced lubrication performance.
Its spin-on design allows for straightforward installation and routine service replacement. Engineered for use in commercial trucks, industrial equipment, forklifts, compressors, agricultural equipment, and select vintage automotive applications, the CQ 85320 bypass oil filter is built to support dependable filtration performance and long-term engine protection.
Features:
- Spin-on bypass lube filter design
- Enhanced cellulose media for efficient contaminant filtration
- Nominal 10-micron filtration rating
- Helps reduce harmful dirt, sludge, and metal particles in engine oil
- Supports improved lubrication system cleanliness
- Designed for industrial, diesel, forklift, and vintage vehicle applications
- Easy spin-on installation and replacement
Specifications:
- Filter Style: Spin-On Lube Filter
- Service Type: Lube
- Filter Type: By-Pass
- Filter Media: Enhanced Cellulose
- Height: 3.79 in (96 mm)
- Outside Diameter Top: 3.66 in (93 mm)
- Thread Size: 5/8-18
- Maximum Flow Rate: 1–3 GPM
- Nominal Micron Rating: 10
Gasket Specifications:
- Attached Gasket
- Outside Diameter: 2.834 in (72 mm)
- Inside Diameter: 2.462 in (63 mm)
- Thickness: 0.200 in (5 mm)
Fitment:
Büssing Trucks
- A13
- A13L
- A13L/1
- Cerbinatto
- Cerbinatto 20
- Diano
- Leoncino 38
- Lupetto 27
- Lupetto 33
- Lupetto A13
- Lupetto A13L
- Lupetto M3
- Lupetto M3L
- Tigrotto A13
- Tigrotto A13L
- Tigrotto A13L/1
- Tigrotto M3
- Tigrotto M3L
Chevrolet Trucks & Buses
- 400SWD – 1992–1998 L4 3.9L 236 CID Isuzu Turbo Diesel
- W4 – 1992–1998 L4 3.9L 236 CID Isuzu Turbo Diesel
Clark Equipment Fork Lift Trucks
- C25B – Continental Engine
- C25P – Continental Engine
- GCS Series – Waukesha 2.9L Engine
- GCS17 (G138WC) – Waukesha D176 Gas & LP Engine
- GCS30 (G138WC) – Waukesha D176 Gas & LP Engine
- GPS Series – Waukesha 2.9L Engine
- GPS20 (GP138WC) – Waukesha D176 Gas & LP Engine
- GPS30 (GP138WC) – Waukesha D176 Gas & LP Engine
Fiat
- 1100 Series – 1959–1967 L4 All
General Motors
- 3.9L Isuzu Diesel Engine (1986–1991)
GMC Trucks & Buses
- 400SWD – 1992–1998 L4 3.9L 236 CID Isuzu Turbo Diesel
- W4 – 1992–1998 L4 3.9L 236 CID Isuzu Turbo Diesel
International Harvester (IHC)
- Forage Harvesters Balers 660 – C146 Engine
Ingersoll-Rand
- Compressors GRR85 – International UC135 Engine
Massey-Ferguson
- Forklift MF4500 – Continental Gas Engine
Renault
- Caravelle – 1960–1961 L4 0.8L 845cc
- Dauphine – 1956–1961 L4 0.8L 845cc / All
